Installing the cylinder head
Checking the camshaftCircuit diagram
4. Main fuse
5. Main switch
9. Battery
14.Neutral switch
25.ECU (engine control unit)
31.Fuel sender
34.Rear brake light switch
35.Front brake light switch
37.Tail/brake light
38.Rear right turn signal light
39.Rear left turn signal light
40.Front right turn signal light
41.Front lef ...
Setting the diagnostic mode
1. Set the main switch to "OFF" and the engine stop switch to "
".
2. Disconnect the self-diagnosis signal connector "1", and then connect the FI
diagnostic tool "2" as
shown.
3. Disconnect the fuel pump coupler.
4. While pressing the "MODE" button, set the main switch to "ON".
NOTE:
...
Installing the rear shock absorber assembly
1. Install:
Rear shock absorber assembly
Relay arm "1"
NOTE:
Install the relay arm as shown in the illustration.
2. Tighten:
Rear shock absorber assembly upper nut
Relay arm nut
Rear shock absorber assembly lower nut
3. Install:
Connecting arms
NOTE:
When ins ...
